Maddiline Carbide Handbike

Maddiline Carbide Handcycle

Decrease your frame weight by 18% with T1000 Carbon Fibre


Carbide is built in an innovative way with the most modern technology of carbon fiber combined with a rigid fork in aluminum alloy to build the best elite racing handcycle on the market.

We are here to fully customize your Carbide. Please check the full order form for options and prices. Let us build your handcycle right the first time! A handcycle expert will assist with the best options for your riding style ensuring the best riding experience only found with Bike-on!


Carbide is built in an innovative way with the most modern technology of carbon fiber combined with a rigid fork in aluminum alloy to build the most performant hand bike today on the market. The collaboration with the champions of this sport has allowed Maddiline to develop their project to offer the athletes maximum sports performance. On the T1000 version, the use of carbon fibers puts the frame “CARBIDE” to the top performance and allows you to obtain the maximum yield, with a considerable saving on weight!


  • Brakes

    Available with Hydraulic Disc or Caliper Brakes

  • Shifters

    2×11 Ultegra Gearset

  • Chainrings

    Choose between double and triple chainring options

  • Chain Guard

    Carbon Fiber

  • Tires

    Clincher or Tubular Tires

  • Frame

    Available in T800 or T1000 Carbon Fiber

  • Wheels

    26”, 20”, 27.5” (Gravel Only) Aluminum Wheelset (Carbon Fiber Upgrade Available), Rear wheels with insertion snap-in 25mm

  • Other

    Crank Arm Length Range From 152.5mm-167.5mm | Clamp on wheels w/ 25mm Axle

  • Fork

    Lightweight & adjustable 7020 Alloy Fork

  • Wheel Camber

    1 or 2 degrees

Frame & Geometry

  • Total Length

    78.5” (20” Rears) 86.6” (26” Rears)

  • Total Width

    23.6” (Without Wheels) 27.6” (With Wheels)

  • Total Weight

    35 lbs (frame)

  • Weight Limit

    280 lbs

  • Wheel Base

    57” (20” Rears) 65” (26” Rears)

  • Ground Clearance

    Frame Clearance: 2.75” (20” Rears) 3.15” (26” Rears)

  • Other

    Footrest – 110mm or 130mm width

Standard Features

  • Tailor-made Precision fitments
  • Fully Customizable
  • Carbide T800 Frame and Mechanical Shifting
  • Shimano Ultegra Caliper Front Wheel Brakes
  • Ergonomic Handgrip
  • Anatomical grips rubber-gel or aluminum tube with the tilt angle of 32°

Included Accessories

  • Aluminum Hand Pedals
  • Lap Belt and Leg Fixation Straps Available
  • Safety Flag
  • Draft Bumper
  • Integral cushion bedsore certificate with the structure to air circulation and fabric covering 3D, detachable and washable
  • Carbon fiber and kevlar adjustable in height and length, with integrated head restraints
