Trident Trikes Stowaway Recumbent

The Stowaway models have always been Trident Trikes’ #1 seller. The Stowaway line offers an incredible component mix at a price other manufacturers can’t touch. Both Stowaway models use our Powder Coated  4130 Cro-Moly Tig Welded Frame, as well as Avid Brakes/ Promax Levers with Parking Brake, Double Wall Alloy Rims, and Ackerman Compensated Crossover Steering, but that is where the similarities end.

Stowaway I

The Stowaway I is a Base Model. It has 27 Speeds (3 x 9) Includes BB5 Brakes, Samox Triple Crankset (52/42/30) with 165mm crankarms. Mesh Seating with angle/height adjustments a MicroShift Marvo LE drivetrain with twist shifters. Rear rack, fenders, rear light, mirror, and accessory mount.

Stowaway II

The Stowaway II is a High Spec Model. It has 30 Speeds (3 x 10) It uses a Microshift Front Derailleur and a Microshift Marvo XE CNC Machined Rear Derailleur. Shifting is done with Bar End Shifters. The Brakes are Avid BB7’s.  The Cassette is an SRAM PG-970 11-36. The Crankset is a High End Forged Crankset with CNC Machined Rings and an Integrated External Bearing  Bottom Bracket. The seat frame, handlebar, and boom are Sandblasted and Anodized Aluminum Alloy. The Stowaway II is available with your choice of either 170mm Cranks or with 160 mm Short Cranks.  Beginning in July 2019, we will also have a few available with 152mm Crankarms. “Z” steering bars are also available for extremely short X Seams. Longer Booms ($50 Additional) will accommodate riders up to 51″ X Seam. Please order these items by phone. Both Stowaway models include an aluminum mesh seat with 3 adjustable seating heights and 4 adjustable seating angles. An optional adjustable neck rest is also now available. Both include an improved Idler system that is as nice as anything on the market. Stowaway 2 also has adjustable handlebars. Kenda Kwest Tires are standard on the Stowaway 1, Schwalbe Tryker Tires are standard on Stowaway 2 Models.  E-Stowaway models use Schwalbe Big Apple Tires. The Rear Tire on the Stowaway 24 is a Schwalbe Marathon.

Also in Stowaway models– we don’t charge you for the extras!! Included with all models is a Rear Rack, a full set of 3 Fenders, a Safety Flag, a Mirror, and a Rear Light.

• Brakes

  Avid BB5 Disc Brakes (2) (I) | Avid BB7 Disc Brakes (2) (II, E)

• Brake Levers

  Promax w/ Lock (I, II) | Electric Cutoff Levers w/ Lock (E)

• Front Derailleur

  Microshift

• Rear Derailleur

  Microshift (I) | Microshift Marvo XE CNC (II, E)

• Shifters

  Microshift Twist Shift (I) | Bar End Shifters (II, E)

• Crankset

  52/42/30 Alloy 165 mm Crankarms (I) | 52/42/30 Integrated or 160mm Crank Arms (II) | Dapu Electric 52/42 (E)

• Bottom Bracket

  170mm or 160mm Crank Arms (II) | 170mm Crankarms Std. (E)

• Chainrings

  CNC Chainrings (II) | CNC Chainrings + Chainguard (E)

• Cassette

  SRAM PG970 11-34 9spd (I) | SRAM PG970 11-36 10spd (II, E)

• Chain

  KMC Z9000 (I) | KMC 10.93 (II, E)

• Front Tires

  Kenda Kwest 100PSI (I) | Schwalbe Trykers 20 x 1.50 (II) | Schwalbe Big Apple 20×2.00 (E)

• Rear Tires

  Kenda Kwest 100PSI (I) | Schwalbe Trykers 20 x 1.50 (II) | Schwalbe Big Apple 20×2.00 (E)

• Wheels

  Rims – Double Wall Alloy | Spokes – SS 14g (I, II) | E-Bike front spokes: SS 14g, E-Bike rear spokes: SS 12g

• Other

  Front Hubs – Custom CNC Alloy Disc Hubs

• Motor

  36v 350 W Dapu Geared Hub Motor w/ Throttle and 6 Assist Modes (E-Stowaway only)

• Total Length

  72 3” (1850mm, varies)

• Total Width

  35.3″ (90cm)

• Total Weight

  38.8 lbs (17.6 KG) (I, II) | 56 LBS (25.4 KG) (E)

• Weight Limit

  275 Lbs

• Wheel Base

  43.3″ (1100 mm) (I) | 44.5″ (1130 mm) (II, E)

• Wheel Track

  31.5″ (80cm)

• Seat Angle

  38-45 degrees

• Seat Height

  11.3/8″ to 13 3/8″

• Rider X-Seam Range

  34 1/4″ to 45 3/8″ (I, II) | 35 1/4″ to 45 3/8″ (E)

• Gear Inch

  17.2”-92.1” (I) | 15.6”-92.1” (20″ Wheel), 19.9″-113.2″ (24″ Wheel) (II) | 23.1”-88.3” (E)
